SPBL bushings, bronze with PTFE plugs (SL4), under water use   SPBL bronze embedded sliding bearing is made of high strength casting bronze, with PTFE solid lubricant embedded in holes on working surface of bearings, then have fine machining on CNC. The bearing combines the advantages of copper alloy and non-metallic friction-reduction material, it has better corrosion resistance performance, so it suits for application in the field of water conservancy machinery.

Structures ①  Bronze backing ②  Solid lubricant plug (PTFE) ③  Solid lubricant film

Typical Applications

• Usable in water
• Serviceable without the need for lubrication. Demonstrates high performance under high-load and low-speed operations.
• Demonstrates superior wear resistance in applications where oil film is seldom produced such as reciprocating motions, oscillation,
   frequent starts and stops, etc.
• Superior chemical resistance and corrosion resistance.
• Standard products are available.

SPBL cylindrical bearings, bronze with PTFE plugs --- Metric Sizes
d	D	L
		20	25	30	35	40	50	60	70	80	90	100	110	120	130	140	150	200
12	18	SPBL-121820
15	21	SPBL-152120
16	22	SPBL-162220		SPBL-162230
18	24	SPBL-182420
20	30	SPBL-203020		SPBL-203030		SPBL-203040
25	35	SPBL-253520	SPBL-253525	SPBL-253530		SPBL-253540	SPBL-253550
30	40	SPBL-304020	SPBL-304025	SPBL-304030		SPBL-304040	SPBL-304050
35	45	SPBL-354520		SPBL-354530	SPBL-354535	SPBL-354540	SPBL-354550	SPBL-354560
40	50			SPBL-405030		SPBL-405040	SPBL-405050	SPBL-405060
	55					SPBL-405540	SPBL-405550	SPBL-405560
45	60			SPBL-456030			SPBL-456050	SPBL-456060
50	60					SPBL-506040	SPBL-506050	SPBL-506060
	65					SPBL-506540	SPBL-506550	SPBL-506560	SPBL-506570
55	70					SPBL-557040		SPBL-557060	SPBL-557070
60	75						SPBL-607550	SPBL-607560	SPBL-607570	SPBL-607580
65	80							SPBL-658060	SPBL-658070	SPBL-658080
70	90							SPBL-709060	SPBL-709070	SPBL-709080	SPBL-709090	SPBL-7090100
75	95								SPBL-759570			SPBL-7595100
80	100							SPBL-8010060		SPBL-8010080	SPBL-8010090	SPBL-80100100	SPBL-80100110
90	110							SPBL-9011060		SPBL-9011080	SPBL-9011090	SPBL-90110100
100	120							SPBL-10012060		SPBL-10012080		SPBL-100120100		SPBL-100120120
110	130											SPBL-110130100	SPBL-110130110
120	140									SPBL-12014080		SPBL-120140100		SPBL-120140120
130	150											SPBL-130150100			SPBL-130150130		SPBL-130150150
140	160											SPBL-140160100				SPBL-140160140
150	170											SPBL-150170100					SPBL-150170150
160	180											SPBL-160180100					SPBL-160180150
170	190											SPBL-170190100					SPBL-170190150
180	200											SPBL-180200100					SPBL-180200150
190	210											SPBL-190210100					SPBL-190210150
200	230																SPBL-200230150	SPBL-200230200
