SOBF guide bushing, flange type, SO#50SP2 copper with graphite

Material Specs
Flanged Guide Bushing


  SOBF guide bushing, flange type, SO#50SP2 copper with graphite

SOBF bearings consist of highly wear-resistance copper cast alloy whose sliding surfaces are evenly provided with a certain percentage of solid lubricant plugs according to work condition, high-strength copper alloy provides a high load-bearing capacity and the solid lubricant can be formation of low friction film.

Under technical dry running conditions, the bearing surface is designed with thick running-in film which
enables the solid lubricant to be transferred to the counter material at the first contact.


①  Solid lubricant film
②  Solid lubricant plug
③  Bronze backing

Material Features
  • Allows maintenance-free and long-life operation;
  • Suitable for high static and dynamic loads;
  • With low and smoothly coefficient of friction and without stick-slip effects;
  • Suitable for dirty, corrosion, impact load and edge loading;
  • The base material provided a good shock-absorbing capacity;
  • Can be used over a large temperature range;
  • Suitable for reciprocating, rotating and oscillating movement with start frequency
    and difficulty to form oil film occasions;
  • With low wear rate and long life service.

How It Works ?

When the mutual friction occurs between two non-lubricated surfaces, the two contacts with the uneven surface of the peak by the shear, stick-slip
and plastic deformation giving rise to friction and wear. Conventional lubricants can significantly reduce these effects, however, the conventional
lubricant will be more and more squeezed out of the contact area with increasing surface which formed the dry friction or boundary lubrication.

With SB#500 (OILES #500) bearings, the lubrication is effected by the sliding material itself, The solid lubricant is released from the friction
material by micro-movement. This gives the sliding partners smooth surfaces with a firmly adhesive solid lubricant film, the solid lubricant film remains within the contact area even under heavy loads. The embedded solid lubricant plugs can be continuously provided to the friction surface to reduce friction resistance and wear, thus make the bearing can be worked under low wear rate and long-life service.

Typical Applications

The product is widely used in continuous casting rolling machine, mining machinery, shipping machinery, turbine, injection machinery, auto mould and so on.

  SOBF guide bushing, flange type, SO#50SP2 copper with graphite  --- Metric Size
























































SOBF-0610  SOBF-0612  SOBF-0810   SOBF-0812   SOBF-0815   SOBF-1010   SOBF-1012   SOBF-1015   SOBF-1017   SOBF-1210   SOBF-1212   SOBF-1215   SOBF-1220   SOBF-1225   SOBF-1230   SOBF-1310   SOBF-1312   SOBF-1315   SOBF-1320   SOBF-1325   SOBF-1330   SOBF-1415   SOBF-1420   SOBF-1425   SOBF-1510   SOBF-1512  SOBF-1515   SOBF-1520   SOBF-1525   SOBF-1530   SOBF-1612   SOBF-1615   SOBF-1618   SOBF-1620   SOBF-1623   SOBF-1625   SOBF-1630   SOBF-1635   SOBF-1640  SOBF-1815   SOBF-1820   SOBF-1825   SOBF-1830   SOBF-1835   SOBF-1840   SOBF-2015   SOBF-2020   SOBF-2025   SOBF-2030   SOBF-2035   SOBF-2040   SOBF-2515  SOBF-2520   SOBF-2525   SOBF-2530   SOBF-2535   SOBF-2540   SOBF-2550   SOBF-3020   SOBF-3025   SOBF-3030   SOBF-3035   SOBF-3040   SOBF-3050   SOBF-31.520  SOBF-31.530  SOBF-31.535  SOBF-31.540  SOBF-3520   SOBF-3525   SOBF-3530   SOBF-3535   SOBF-3540   SOBF-3550   SOBF-4020   SOBF-4025   SOBF-4030   SOBF-4035  SOBF-4040   SOBF-4050   SOBF-4525   SOBF-4530   SOBF-4535   SOBF-4540   SOBF-4550   SOBF-5030   SOBF-5035   SOBF-5040   SOBF-5050   SOBF-5060   SOBF-5540  SOBF-5560   SOBF-6040   SOBF-6050   SOBF-6060   SOBF-6080   SOBF-6368   SOBF-6560   SOBF-7050   SOBF-7080   SOBF-7560   SOBF-8060   SOBF-8080   SOBF-80100  SOBF-9060   SOBF-9080   SOBF-10080   SOBF-100100   SOBF-12080   SOBF-120100   SOBF-13080   SOBF-130100   SOBF-14080   SOBF-140100   SOBF-150100  SOBF-150120   SOBF-160100   SOBF-160120
