Structures 1. Sinter bronze powder: good wear resistance and excellent load carrying capacity. 2. Steel backing: provides exceptionally high load carrying capacity, excellent heat dissipation. 3. Copper plating thickness 0.002mm provides good corrosion resistance.

Bronze Alloys Available

Composition Analysis of Bronze Alloy SAE792,SAE799, SAE48, SAE783

Types for Bi-Metallic Bushing's Grooves and Indents

Lock Types for Bi-Metallic Bushings

Typical Applications

The main applications are in Automotive and Industrial products.
Automotive: McPherson struts and shock absorbers, doors, bonnets and tailgate hinges, steering columns, clutches, gearbox selector fork guides, wiper arms, power steering pumps, pedal bushes, ABS equipment, etc.
Industrial: Aerospace, agricultural equipment, construction equipment, material handling equipment, forming machines-metal, plastic and rubber, office equipment, medical and scientific equipment, packaging equipment, pneumatic and hydraulic cylinders, pumps and motors, railroad and tramways, textile machinery, valves, etc.
Bimetal Bushings‘ applications for King pin, Spring eyes, Trunion, Piston pin, Rocker arm, Connecting rod, Transmission system, Distributor, Clutch, pilot, Starter, Generator, Oil pump, gear pump, Water pump, Cam shaft, Intermediate shaft, Balance shaft.
Bimetal Washers’ applications for Main bearing, Cam shaft, Crank shaft, Distributor, Transmission system, Oil pump, Ram pump, vane pump and other applications.
Engine Bearings’ application for Cam shaft, Crank (main), Con. Rod (big end) and other applications of engine bearing.

Other Standard Wrapped Bimetal Bushing Shapes


SAE-792 Bimetallic Bush		SAE-799 Bimetallic Bush		SAE-48 Bimetallic Bush
SAE-783 Bimetallic Bush		Flanged Bimetallic Bush		Bimetallic Thrust Washers
